"Sidon"

"Sidon"

6 String Guitar

Sales Pitch:

27 frets for extreme upper-end range, great for right hand tapping. Upper access to the extra frets is also easy with left hand. The guitar is a different take on modern guitar design so it should feel somewhat familiar, yet still very unique. The Wilkinson VS100 tremolo provides adequate tuning stability while allowing for the flexibility of non-locking nuts. Every part of the bridge locks down so there are no loose parts potentially sucking up sustain, unintentional vibrations, or affecting tuning stability.

Woods:

Black limba and chechen are two equally gorgeous and great sounding guitar woods. The chechen fretboard has a beautiful waterfall-like grain with so many natural colors ranging from red orange to black. Limba(AKA korina) has been a well established guitar wood for decades that has recently become popular again with boutique builders. "Black limba" refers to highly figured grain featuring darker streaks and other colors making for one of the most interesting looking body woods for electric guitar bodies. Tonally, single notes soar in the mid and upper mid range with long sustain.

Tuners - From Gotoh:

Gotoh's sleek modern design with compact cast housings and sealed gears, plus Magnum Lock® string posts to help keep tremolo guitars in tune. The post automatically locks the string as you tune. Rock-Solid™ string posts eliminate looseness, for improved tuning stability.
- 18:1 gear ratio


Pickups - From Dimarzio:


Bridge Pickup:
A high-output pickup designed for the bridge position. The Mirage™ Bridge has a bold tone with enough focus to be heard clearly in a 3-guitar mix.
Magnet - Ceramic
Resistance - 11.4 Kohm

Neck Pickup:
This fully humbucking pickup features a bell-like top end for smoothness and an opened-up bass for balance.
Magnet - NEO
Resistance - 8.2 Kohm

Specs.

Scale Length 25.5"
# of Strings 6
# of Frets 27
Fretboard Radius 16"
Neck Type Handcarved, D shape
Neck Width @nut: 42.8mm
@24th: 56.5mm
Neck Thickness @1st: 19mm
@12th 20.5mm
String Spacing @nut: 35.3mm
@bridge: 54mm
Body Thickness 1-3/4"
Neck Joint Bolt-on, deep access
Headstock Type 10 degree angle, w/ volute
Overall Length 38-1/4"
Weight 7 lbs 13.5 oz

Parts/Materials

Pickups Dimarzio Mirage neck, double blade
Dimarzio Mirage bridge
Switching 5-way Schaller Megaswitch
1. Neck 2. Neck(p) 3. Both 4. Bridge(p) 5. Bridge
Bridge Gotoh Wilkinson VS100, black
Tuners Gotoh 510, black
Fret Material Jumbo(#150), Stainless steel
Fret Markers Turquoise stone, black pearl rings
Nut Material Bone
Trussrod 2-way adjustable
Body Wood Black Limba
Neck Wood Black Limba, Chechen
Fretboard Wood Chechen
Finish Type Body: Hand rubbed oil
Neck: Hand rubbed oil, hard wax
